Technical Parameters
Carrier frequency range: 600MHz-690MHz (4-band frequency range optional)
Modulation: FM
Maximum frequency deviation: + - 45KHz
Frequency response: 50Hz-15KHz
Signal to noise ratio (S/N): 105dB (A)
Distortion (1KHz): <0.3%
Operating temperature: -10 degrees to 55 degrees
Working distance: 100 meters (the best environment)
Power consumption: 8W
Static power: 3W
Receiver
Oscillation mode: PLL (digital frequency synthesizer)
Spurious Suppression: ≥80dB
Mirror suppression: ≥80dB
Sensitivity: 5dBuV
Audio output level: balanced output (XLR output jack): 250mV / 600Ω
Unbalanced output (1/4 "output jack): 400mV / 3KΩ
Operating voltage: DC12-18V
Working current: ≤ 350mA
Chassis Size: 420 * 175 * 42mm
In the case of
Handheld launchers
RF power output: up to 30mW (depending on applicable national specification)
Oscillation mode: PLL (digital frequency synthesizer)
Transmitting frequency stability: <30ppm
Dynamic range: ≥ 100dB (A)
Frequency response: 50Hz-15KHz Maximum
