Product Description
--Using traditional FM modulation technology with superior RF performance and audio performance
--Full digital solution, stable product performance
--60 adjustable frequency points for each of 8 channels
--With automatic search for clean channels
-- Hand microphone with optional smart mute function
Transmitter Specifications:
Frequency Error: <15ppm
Transmitting power: ordinary <10mW
Transmitter working current: <135mA
Transmitter power supply: 1.5V X 2 (2 AA batteries) (18650 battery version can be specified)
System metrics:
Frequency range: 470~960MHz (frequency range and frequency points can be customized according to customer requirements)
Frequency stability: ±0.005%
Dynamic range: >100dB
Overall Distortion: < 0.5%
Comprehensive signal-to-noise ratio: >100dB
Receiver Specifications:
Antenna interface: BNC socket
Receive sensitivity: < -107dBm@20dB SINAD
Receiver power supply: 11-14V (rated 12V) (one for four using >1000mA adapter)
Output mode (transmitter MIC input 50mV/1KHZ): independent balanced output (XLR): 230mV±15mV
Mixed output (6.35mm): 230mV±15mV
Receiver working current: one for four: <370mA,
Transmitter Specifications:
Frequency Error: <15ppm
Transmitting power: ordinary <10mW, (high power <100mW, powered by 3.6V 18650 lithium battery)
Transmitter working current: <135mA
Transmitter power supply: 1.5V X 2 (2 AA batteries) (18650 battery version can be specified)
