LIVE SOUND · RENTAL · SIX INDEPENDENT AUX MIXES
Build a Monitor Mix Around Each Performer's Needs
Build a monitor mix around each performer’s needs. The ELEGAUDIO MX3210 brings 26 microphone inputs and six independently adjustable AUX mixes to live sound and rental applications. Its 7-inch touchscreen supports on-console control, while a 2-in/2-out USB audio interface at 48 kHz handles stereo recording and playback. Tell us about your application so we can discuss the right setup together.
DISCUSS YOUR MX3210 APPLICATION
MX3210 Quick Specifications
| Product Type | Professional digital mixing console |
|---|
| SKU / Model | U00042 / MX3210 |
|---|
| 32-Channel Architecture | 26 mono microphone inputs + 2 stereo input pairs (4 channels) + 2 digital channels |
|---|
| AUX Mixes | AUX 1–6: six independently adjustable mixes |
|---|
| USB Audio | USB-B, 2-in/2-out at 48 kHz for stereo recording and playback |
|---|
| Digital Output | USB left/right audio channels; not two separate physical digital output ports |
|---|
| Display | 7-inch 1280 × 800 capacitive multi-touchscreen |
|---|
| Remote Control | Built-in Wi-Fi hotspot, web server and browser-based control |
|---|
| Bluetooth Range | Nominally 12 m; actual range depends on the operating environment |
|---|
Six Independent AUX Mixes
AUX 1–6 can each carry an independently adjusted monitor or zone mix. Two AUX outputs can be assigned as left and right for a stereo monitor mix, using both AUX outputs. Native AUX linking is not stated, so stereo operation should be planned as two separately managed mixes.
32-Channel Input Architecture
The 32-channel count consists of 26 mono microphone inputs, two stereo input pairs contributing four channels, and two digital channels. This count distinguishes physical mono inputs, stereo pairs and digital sources.
Channel and Output Processing
Input processing includes high-pass and low-pass filters, parametric EQ, compressor, noise gate and phase adjustment. Microphone channels provide digitally controlled gain and independently switchable phantom power. Output processing includes crossover, EQ, compression and delay. Three manually selected frequency-shift levels can assist with feedback management, but they do not guarantee feedback-free operation.
USB Recording and Playback
The USB-B connection provides a bidirectional stereo audio interface: two inputs and two outputs at 48 kHz. The stated digital output refers to the USB left and right audio channels, not two separate physical digital output connectors.
Wireless Browser Control
The built-in Wi-Fi hotspot and web server support browser-based control from a compatible phone, tablet or computer on the same network. The external Bluetooth receiving antenna is specified at a nominal 12 m; walls, interference and device placement can affect actual range.
Live Workflow Features
- Customizable channel icons and editable channel names
- Real-time level meters and touchscreen navigation
- Copyable input and output parameters
- Mute groups, DCA groups and emergency mute
- Scene saving, recall and power-off memory
- Key lock and master encoder navigation
Typical Applications
Live performances · Event production · Rental companies · Houses of worship · Schools and auditoriums · Conference rooms · Bars and clubs · Recording and live streaming · Fixed sound installations
Discuss Your MX3210 Application
Send your destination country and intended application so ELEGAUDIO can discuss a suitable configuration. Expected quantity is optional at this stage. Pricing, MOQ, lead time, warranty, packaging and OEM/ODM options are confirmed for the current product version before quotation.
DISCUSS YOUR MX3210 APPLICATION
Frequently Asked Questions
How are the 32 input channels counted?
The count is 26 mono microphone inputs, two stereo input pairs contributing four channels, and two digital channels.
How many independent AUX mixes are available?
AUX 1–6 provide six independently adjustable mixes. Two can be used as left and right for a stereo monitor mix, consuming both AUX outputs; native linking is not stated.
What does the USB audio interface provide?
USB-B provides 2-in/2-out stereo audio at 48 kHz for recording and playback.
Are there two physical digital output ports?
No. The stated digital output refers to the USB left and right audio channels.
How does the feedback frequency shifter work?
It offers three manually selected frequency-shift levels as an auxiliary feedback-management tool. It does not guarantee that feedback will not occur.
What is the Bluetooth range?
The nominal range is 12 m. Actual performance depends on interference, obstacles and device placement.
Can the mixer be controlled from a browser?
Yes. A compatible phone, tablet or computer can connect through the built-in Wi-Fi hotspot and web server.
Discuss Your MX3210 Application
Country and application are the useful starting points. Quantity is optional.
