MX1610 provides a 16-channel input architecture with 12 microphone inputs, 2 stereo channels and 2 digital stereo channels. Its analogue-style workflow, 7-inch multi-touch display and browser-based remote control support fast operator onboarding for compatible live, rental and installation systems.
MX1610 provides a 16-channel input architecture with 12 microphone inputs, 2 stereo channels and 2 digital stereo channels. Its analogue-style workflow, 7-inch multi-touch display and browser-based remote control support fast operator onboarding for compatible live, rental and installation systems.
| Model | MX1610 |
| Total input channels | 16 |
| Microphone inputs | 12 |
| Stereo channels | 2 |
| Digital stereo channels | 2 |
| AUX outputs | 6 |
| Other outputs | Stereo main, monitor and 2 digital outputs |
| Input processing | High-pass/low-pass filters, parametric EQ, compressor, noise gate and phase adjustment |
| Microphone-channel features | Digitally controlled gain and independent phantom power |
| Output processing | Crossover, EQ, compressor, delay and 3-stage anti-feedback frequency shifter |
| Effects | Two independent stereo processors; preset effects and 16 programmable custom modes |
| USB functions | Playback, recording and USB audio interface |
| Display | 7-inch 1280 × 800 capacitive multi-touchscreen |
| Remote control | Built-in Wi-Fi hotspot and browser-based web server |
| Bluetooth range | More than 12 m, as stated |
| Security | Administrator and custom-user password protection |
| Control workflow | Mute groups, DCA groups, key lock, scene save/recall and emergency mute |
| SKU | U00039 |
Relevant to compatible live sound, rental, event, worship, education and fixed-installation systems. Buyers should confirm input/output requirements, stagebox or protocol integration, regional power, accessories and packing.
Contact ELEGAUDIO for pricing, quantities, availability, packing details and project requirements. Include destination market, quantity and intended application.
Can the mixer be controlled from a browser?
Yes. A built-in Wi-Fi hotspot and web server are stated.
Does it support USB audio?
Yes. USB playback, recording and audio-interface functions are stated.
How many AUX outputs are available?
Six.
Can settings be saved and recalled?
Yes. System settings and scene presets can be saved and recalled.
