BMG-04U 4-Channel Professional Mixing Console
BMG-04U combines analog microphone/stereo mixing, channel filtering/EQ, effects and a simple USB audio interface.
SKU:M91117
PROFESSIONAL AUDIO · B2B SOURCING
BMG-04U provides 2 mono plus two stereo input channels, one AUX output, 256 digital presets and 48 kHz/16-bit USB 2.0 audio for compatible small live and recording workflows.
BMG-04U provides 2 mono plus two stereo input channels, one AUX output, 256 digital presets and 48 kHz/16-bit USB 2.0 audio for compatible small live and recording workflows.
| Model | BMG-04U |
| Inputs | 2 mono + 2 stereo |
| Headphones | 1 |
| AUX outputs | 1 |
| Frequency response | +0.5/-1.5 dB, 20 Hz–48 kHz |
| THD+N | 0.03% at +14 dBu / 20 Hz–20 kHz; 0.005% at +24 dBu / 1 kHz |
| Noise | Input -128 dBu / output -102 dBu |
| Crosstalk | -78 dB at 1 kHz |
| Pad | 20 dB |
| HPF | 80 Hz, 12 dB/oct |
| High EQ | ±15 dB at 10 kHz |
| Mid EQ | ±15 dB at 2.5 kHz |
| Low EQ | ±15 dB at 100 Hz |
| Peak LED | 3 dB below clipping |
| Meter | 2×5 LEDs: clip, +6, 0, -10, -20 dB |
| Effects | 256 presets |
| USB audio | USB 2.0, 48 kHz, 16 bit |
| Phantom power | 48 V |
| AC input | 100–240 V, 50/60 Hz |
| Power consumption | 36 W |
| SKU | M91117 |
For compatible streaming, small live, rehearsal and recording. Confirm USB channel routing/driver support, detailed connectors, effect list, dimensions and included cable.
Contact ELEGAUDIO for pricing, quantities, availability, packing details and project requirements. Include destination market, quantity and intended application.
What input configuration is provided?
2 mono plus two stereo channels.
How many effects are included?
256 presets.
What USB format is stated?
USB 2.0 at 48 kHz / 16 bit.
Does it support universal mains input?
Yes, 100–240 V at 50/60 Hz.
Request current pricing, availability and distributor support.
GET A QUOTE
